Model:13T 590210 J3

Benchmarking model: Firestone W01M585518
Swap models:Vibracoustic V1D28A-21; ContiTech 1R14-860
Product features: designed for China's road conditions and use conditions, the piston is strengthened, and the internal design has anti-collision buffer block, which is more safe and durable. There is no need to add a new base plate.

  • Product details

Bearing capacity at 7bar internal pressure 42kN
Maximum allowable internal pressure at standard height 8.5bar
Burst pressure >21bar
Maximum outer diameter 348mm
Minimum installation space required 375mm
Maximum allowable height 590mm
Stop height 210mm
proper temperature -40℃~60℃
Weight
Piston material steel
