Model:13T 590210 J2
Benchmarking model: Firestone W01M585518
Swap models:Vibracoustic V1D28A-21; ContiTech 1R14-860
Product features: designed for China's road conditions and use conditions, the piston is strengthened, and the internal design has anti-collision buffer block, which is more safe and durable. There is no need to add a new base plate.
- Product details
Bearing capacity at 7bar internal pressure | 42kN |
Maximum allowable internal pressure at standard height | 8.5bar |
Burst pressure | >21bar |
Maximum outer diameter | 348mm |
Minimum installation space required | 375mm |
Maximum allowable height | 590mm |
Stop height | 210mm |
proper temperature | -40℃~60℃ |
Weight | |
Piston material | steel |
